South Australian Railways "T" Class on hire.
| Class: | NMA | |
| Builder: | South Australian Railways, Islingston workshops
James Martin, Gawler, South Australia. Walkers Ltd, Maryborough, Queensland | |
| Introduced: | 1944 | |
| Number in Class: | 4 | |
| Wheel Arrangement: | 4-8-0 | |
| Driving Wheel Diameter: | 3 ft. 7 in. | |
| Cylinders: | Number: | 2 |
| Position on frame: | Outside | |
| Diameter x stroke: | 16½ in. x 22 in. | |
| Valve Gear: | Stephenson | |
| Heating Surface: | Tubes: | 939 square feet |
| Superheater: | 136 square feet | |
| Firebox: | 109 square feet | |
| Grate Area: | 17.3 square feet | |
| Boiler Pressure: | 185 lbs p.s.i. | |
| Tractive Effort: | 21,904 lbs | |
| Coal Capacity: | 8 tons | |
| Water Capacity: | 2,500 gallons | |
| Weight in Working Order: | 78 tons 8 cwt | |
| Maximum Axle Load: | 8 tons 17 cwt | |
| Overall Length | 52 ft. 11 in. | |
Steam locomotive with 4-8-0 wheel arrangement, ex "T" class hired from the South Australian Railways. It was built by the Islington Workshops of the South Australian Railways.
| 26.3.1907 | Entered service on the South Australian Railways as No.46. Built by the Islington Workshops, builder No.7. |
| 4.1942 | Hired for use on the Central Australia Railway. |
| 1943 | returned to South Australian Railways. |
Steam locomotive with 4-8-0 wheel arrangement, ex "T" class hired from the South Australian Railways. It was built by James Martin.
| 14.7.1913 | Entered service on the South Australian Railways as No.212. Built by the "James Martin", Gawler, South Australia, builder No.214. |
| 5.1942 | Hired for use on the Central Australia Railway. |
| 1943 | returned to South Australian Railways. |
Steam locomotive with 4-8-0 wheel arrangement, ex "T" class hired from the South Australian Railways. It was built by Walkers Ltd.
| 28.8.1917 | Entered service on the South Australian Railways as No.256. Built by the "Walkers Ltd", Maryborough, Queensland, builder No.281. |
| 6.1942 | Hired for use on the Central Australia Railway. |
| 1943 | returned to South Australian Railways. |
Steam locomotive with 4-8-0 wheel arrangement, ex "T" class hired from the South Australian Railways. It was built by James Martin.
| 14.7.1913 | Entered service on the South Australian Railways as No.50. Built by the "James Martin", Gawler, South Australia, builder No.1934. |
| 5.1942 | Hired for use on the Central Australia Railway. |
| 1943 | returned to South Australian Railways. |
